The Ultimate Storage System Plan
DIY 3 Unit Storage System digital plans! Each size unit has it's own set of plans!
Dimensions are in the photos and all storage container sizes for each unit are listed below.
*The enclosure for the units is not included in the plans.
Because this is a customizable system (you can mix and match unit quantity and sizes) and every workspace has different ceiling heights, the plywood or osb enclosure will require lengths to fit your workspace.
If you choose to enclose the system, refer to the video linked below:
https://www.youtube.com/watch?v=VVtfASmg2msOr on youtube at https://www.youtube.com/c/MatthewPeechWoodworkingAndDIY
*Placement of the system in your workspace will also determine which unit of the system will have the side enclosed.
This is a digital product intended to guide you through the steps of the build for personal use in your home garage, or workshop, or to use to make these for your woodworking business!
This set of plans consists of 3 different sets of plans that total 39 pages of simple instructions including exploded views, x-ray views, all assembly steps, exact measurements, and a detailed cut and part list.
24” Unit
Designed for 66Q Totes (Or any storage devices that will fit the below dimensions)
Shelf size - 24” wide x 48” long ( 31 1/4” Space between shelves)
Sizes of Totes seen in the photo and video for this unit:
66 Qt (62L)
Brand - Sterilite (Purchased from Walmart)
24” L x 16” W x 13 ⅞ H
26” Unit
Designed for 27 Gallon (108 Qt.) Totes (Or any storage devices that will fit the below dimensions)
Shelf size - 26” wide x 48” long ( 31 1/4” Space between shelves)
Sizes of Totes seen in the photo and video for this unit:
66 Qt (62L)
Brand - Sterilite (Purchased from Walmart)
24” L x 16” W x 13 ⅞ H
27 Gallon (108Q)
Brand - Performax (Purchased from Menards)
28 ¼” L x 19 ½” W x 15 ¼” H (May be listed as 28 ¼” W x 15 ¼” H x 19 ½” D)
27 Qt (26L)
Brand - Sterilite (Purchased from Walmart)
16 ½” L x 13” W x 12 ¼” H
16” Unit
Designed for 27Q Totes (Or any storage devices that will fit the below dimensions)
Sizes of Totes seen in the photo and video for this unit:
27 Qt (26 L)
Brand - Sterilite (Purchased from Walmart)
16 ½” L x 13” W x 12 ¼” H
15 Qt (14 L)
Brand - Sterilite (Purchased from Walmart)
16 ½” L x 13” W x 6 ⅝” H
7 Qt. (6.6 L)
Brand Sterilite (Purchased from Walmart)
14 ⅜” L x 8 ¼” W x 6” H
*Garage or workspace ceiling height will determine the quantity of each that will fit on the top shelf.
*All building material has different weight limits. Make sure to test your shelves and structure before loading it.
*The moving parts can cause injury to fingers and arms if not used correctly. Do not stand or climb on shelves.
*This is a downloadable digital plan and not an actual product
*Totes are not included but recommended sizes and brands tested are listed in the plans
*Make sure to download and save the plan after purchase. The link is only available for 24 hours!
